雅阁架空线路辅助设计软件(WCAD)操作手册之第二章格式平断面

一、格式图框与格式平断面

格式图框与格式平断面其实都是格式平断面，前者带了图框而已。

格式平断面指该AutoCAD文件是符合本软件要求的图形文件。利用这个文件进行架空线路设计时，本软件自动标注档距及耐张段的相关计算数据，而利用非格式平断面的文件进行架空线路设计时，不会在图中标注档距及耐张段的相关计算数据。

格式平断面仍然是标准的AutoCAD文件。

二、生成格式图框

进入<生成格式图框>页面，输入纵横比例值及高程的上下限，点击“生成图框”按钮。本软件自动连接AutoCAD，并生成格式图框的表头，用户根据需要对图框进行延长或裁剪。

三、标记平断面

对于已经存在的平断面图纸，本软件通过标记可以改变其为格式平断面。打开已经存在的平断面图纸，进入<标记平断面>页面，点击“标记平断面”按钮，按照页面红色箭头所指位置，在AutoCAD作图区域输入数字化点，当前图纸将会成为格式平断面。

雅阁架空线路辅助设计软件(WCAD)操作手册之第一章项目

项目管理机制

本软件建立项目管理机制，并形成架空线路项目文件，该类型文件扩展名为otl。

架空线路项目文件是一个文件名称的集合，每个架空线路设计过程都会有一个架空线路项目文件，主要包含架空线路设计过程中使用到的相关支持文件名称以及生成的相关成果文件名称，这些所有的文件都是独立的。

目的

建立项目管理机制可以协调所涉及文件，并保障相关文件在使用过程中的一致性和正确性。

架空线路项目文件丢失并不影响设计的进行，只是原来的支持文件名称需要重新选择，比如，上次使用的杆塔文件名称需要重新选择，生成的计算报告名称需要重新选取，诸如此类。

沁园春·雪

Windows 消息定义(6)

RB_GETBANDINFO = (WM_USER + 5),

RB_SETBANDINFOA = (WM_USER + 6),

RB_SETPARENT = (WM_USER + 7),

RB_HITTEST = (WM_USER + 8),

RB_GETRECT = (WM_USER + 9),

RB_INSERTBANDW = (WM_USER + 10),

RB_SETBANDINFOW = (WM_USER + 11),

RB_GETBANDCOUNT = (WM_USER + 12),

RB_GETROWCOUNT = (WM_USER + 13),

RB_GETROWHEIGHT = (WM_USER + 14),

RB_IDTOINDEX = (WM_USER + 16),

RB_GETTOOLTIPS = (WM_USER + 17),

RB_SETTOOLTIPS = (WM_USER + 18),

RB_SETBKCOLOR = (WM_USER + 19),

RB_GETBKCOLOR = (WM_USER + 20),

RB_SETTEXTCOLOR = (WM_USER + 21),

RB_GETTEXTCOLOR = (WM_USER + 22),

RB_SIZETORECT = (WM_USER + 23),

RB_SETCOLORSCHEME = CCM_SETCOLORSCHEME,

RB_GETCOLORSCHEME = CCM_GETCOLORSCHEME,

RB_BEGINDRAG = (WM_USER + 24),

RB_ENDDRAG = (WM_USER + 25),

RB_DRAGMOVE = (WM_USER + 26),

RB_GETBARHEIGHT = (WM_USER + 27),

RB_GETBANDINFOW = (WM_USER + 28),

RB_GETBANDINFOA = (WM_USER + 29),

RB_MINIMIZEBAND = (WM_USER + 30),

RB_MAXIMIZEBAND = (WM_USER + 31),

RB_GETDROPTARGET = (CCM_GETDROPTARGET),

RB_GETBANDBORDERS = (WM_USER + 34),

RB_SHOWBAND = (WM_USER + 35),

RB_SETPALETTE = (WM_USER + 37),

RB_GETPALETTE = (WM_USER + 38),

RB_MOVEBAND = (WM_USER + 39),

RB_SETUNICODEFORMAT = CCM_SETUNICODEFORMAT,

RB_GETUNICODEFORMAT = CCM_GETUNICODEFORMAT,

RB_GETBANDMARGINS = (WM_USER + 40),

RB_SETWINDOWTHEME = CCM_SETWINDOWTHEME,

RB_PUSHCHEVRON = (WM_USER + 43),

TTM_ACTIVATE = (WM_USER + 1),

TTM_SETDELAYTIME = (WM_USER + 3),

TTM_ADDTOOLA = (WM_USER + 4),

TTM_ADDTOOLW = (WM_USER + 50),

TTM_DELTOOLA = (WM_USER + 5),

TTM_DELTOOLW = (WM_USER + 51),

TTM_NEWTOOLRECTA = (WM_USER + 6),

TTM_NEWTOOLRECTW = (WM_USER + 52),

TTM_RELAYEVENT = (WM_USER + 7),

TTM_GETTOOLINFOA = (WM_USER + 8),

TTM_GETTOOLINFOW = (WM_USER + 53),

TTM_SETTOOLINFOA = (WM_USER + 9),

TTM_SETTOOLINFOW = (WM_USER + 54),

TTM_HITTESTA = (WM_USER +10),

TTM_HITTESTW = (WM_USER +55),

TTM_GETTEXTA = (WM_USER +11),

TTM_GETTEXTW = (WM_USER +56),

TTM_UPDATETIPTEXTA = (WM_USER +12),

TTM_UPDATETIPTEXTW = (WM_USER +57),

TTM_GETTOOLCOUNT = (WM_USER +13),

TTM_ENUMTOOLSA = (WM_USER +14),

TTM_ENUMTOOLSW = (WM_USER +58),

TTM_GETCURRENTTOOLA = (WM_USER + 15),

TTM_GETCURRENTTOOLW = (WM_USER + 59),

TTM_WINDOWFROMPOINT = (WM_USER + 16),

TTM_TRACKACTIVATE = (WM_USER + 17),

TTM_TRACKPOSITION = (WM_USER + 18),

TTM_SETTIPBKCOLOR = (WM_USER + 19),

TTM_SETTIPTEXTCOLOR = (WM_USER + 20),

TTM_GETDELAYTIME = (WM_USER + 21),

TTM_GETTIPBKCOLOR = (WM_USER + 22),

TTM_GETTIPTEXTCOLOR = (WM_USER + 23),

TTM_SETMAXTIPWIDTH = (WM_USER + 24),

TTM_GETMAXTIPWIDTH = (WM_USER + 25),

TTM_SETMARGIN = (WM_USER + 26),

TTM_GETMARGIN = (WM_USER + 27),

TTM_POP = (WM_USER + 28),

TTM_UPDATE = (WM_USER + 29),

TTM_GETBUBBLESIZE = (WM_USER + 30),

TTM_ADJUSTRECT = (WM_USER + 31),

TTM_SETTITLEA = (WM_USER + 32),

TTM_SETTITLEW = (WM_USER + 33),

TTM_POPUP = (WM_USER + 34),

TTM_GETTITLE = (WM_USER + 35),

TTM_SETWINDOWTHEME = CCM_SETWINDOWTHEME,

SB_SETTEXTA = (WM_USER+1),

SB_SETTEXTW = (WM_USER+11),

SB_GETTEXTA = (WM_USER+2),

SB_GETTEXTW = (WM_USER+13),
